Monitoring Azure OpenAI Service
Article • 03/14/2023
When you have critical applications and business processes relying on Azure resources, you want to
monitor those resources for their availability, performance, and operation.
This article describes the monitoring data generated by Azure OpenAI Service. Azure OpenAI is part of
Cognitive Services, which uses Azure Monitor. If you're unfamiliar with the features of Azure Monitor
common to all Azure services that use it, read Monitoring Azure resources with Azure Monitor.
Azure OpenAI collects the same kinds of monitoring data as other Azure resources that are described in
Monitoring data from Azure resources.
Platform metrics and the Activity log are collected and stored automatically, but can be routed to other
locations by using a diagnostic setting.
Resource Logs aren't collected and stored until you create a diagnostic setting and route them to one or
more locations.
See Create diagnostic setting to collect platform logs and metrics in Azure for the detailed process for
creating a diagnostic setting using the Azure portal, CLI, or PowerShell. When you create a diagnostic
setting, you specify which categories of logs to collect.
Keep in mind that using diagnostic settings and sending data to Azure Monitor Logs has additional costs
associated with it. To understand more, consult the Azure Monitor cost calculation guide.
The metrics and logs you can collect are discussed in the following sections.
You can analyze metrics for Azure OpenAI by opening Metrics which can be found underneath the
Monitoring section when viewing your Azure OpenAI resource in the Azure portal. See Getting started
with Azure Metrics Explorer for details on using this tool.
Azure OpenAI is a part of Cognitive Services. For a list of all platform metrics collected for Cognitive
Services and Azure OpenAI, see Cognitive Services supported metrics.
For the current subset of metrics available in Azure OpenAI:
Monitoring data
Collection and routing
Analyzing metrics
Azure OpenAI Metrics
https://learn.microsoft.com/en-us/azure/azure-monitor/overview
https://learn.microsoft.com/en-us/azure/azure-monitor/essentials/monitor-azure-resource
https://learn.microsoft.com/en-us/azure/azure-monitor/essentials/monitor-azure-resource#monitoring-data-from-azure-resources
https://learn.microsoft.com/en-us/azure/azure-monitor/platform/diagnostic-settings
https://learn.microsoft.com/en-us/azure/azure-monitor/logs/cost-logs
https://learn.microsoft.com/en-us/azure/azure-monitor/essentials/metrics-getting-started
https://learn.microsoft.com/en-us/azure/azure-monitor/essentials/metrics-supported#microsoftcognitiveservicesaccounts
18/05/2023, 11:16 Monitoring Azure OpenAI Service - Azure Cognitive Services | Microsoft Learn
https://learn.microsoft.com/en-us/azure/cognitive-services/openai/how-to/monitoring 2/5
Metric Exportable
via
Diagnostic
Settings?
Metric
Display
Name
Unit Aggregation
Type
Description Dimensions
BlockedCalls Yes Blocked
Calls
Count Total Number of
calls that
exceeded
rate or
quota limit.
ApiName,
OperationName, Region,
RatelimitKey
ClientErrors Yes Client
Errors
Count Total Number of
calls with
client side
error (HTTP
response
code 4xx).
ApiName,
OperationName, Region,
RatelimitKey
DataIn Yes Data In Bytes Total Size of
incoming
data in
bytes.
ApiName,
OperationName, Region
DataOut Yes Data Out Bytes Total Size of
outgoing
data in
bytes.
ApiName,
OperationName, Region
FineTunedTrainingHours Yes Processed
FineTuned
Training
Hours
Count Total Number of
Training
Hours
Processed
on an
OpenAI
FineTuned
Model
ApiName,
ModelDeploymentName,
FeatureName,
UsageChannel, Region
Latency Yes Latency MilliSeconds Average Latency in
milliseconds.
ApiName,
OperationName, Region,
RatelimitKey
Ratelimit Yes Ratelimit Count Total The current
ratelimit of
the ratelimit
key.
Region, RatelimitKey
ServerErrors Yes Server
Errors
Count Total Number of
calls with
service
internal
error (HTTP
response
code 5xx).
ApiName,
OperationName, Region,
RatelimitKey
SuccessfulCalls Yes Successful
Calls
Count Total Number of
successful
calls.
ApiName,
OperationName, Region,
RatelimitKey
TokenTransaction Yes Processed
Inference
Count Total Number of
Inference
ApiName,
ModelDeploymentName,
18/05/2023, 11:16 Monitoring Azure OpenAI Service - Azure Cognitive Services | Microsoft Learn
https://learn.microsoft.com/en-us/azure/cognitive-services/openai/how-to/monitoring 3/5
Metric Exportable
via
Diagnostic
Settings?
Metric
Display
Name
Unit Aggregation
Type
Description Dimensions
Tokens Tokens
Processed
on an
OpenAI
Model
FeatureName,
UsageChannel, Region
TotalCalls Yes Total Calls Count Total Total
number of
calls.
ApiName,
OperationName, Region,
RatelimitKey
TotalErrors Yes Total
Errors
Count Total Total
number of
calls with
error
response
(HTTP
response
code 4xx or
5xx).
ApiName,
OperationName, Region,
RatelimitKey
Data in Azure Monitor Logs is stored in tables where each table has its own set of unique properties.
All resource logs in Azure Monitor have the same fields followed by service-specific fields. The common
schema is outlined in Azure Monitor resource log schema.
The Activity log is a type of platform log in Azure that provides insight into subscription-level events. You
can view it independently or route it to Azure Monitor Logs, where you can do much more complex
queries using Log Analytics.
For a list of the types of resource logs available for Azure OpenAI and other Cognitive Services, see
Resource provider operations for Cognitive Services
To explore and get a sense of what type of information is available for your Azure OpenAI resource a
useful query to start with once you have deployed a model and sent some completion calls through the
playground is as follows:
Analyzing logs
Kusto queries
） Important
When you select Logs from the Azure OpenAI menu, Log Analytics is opened with the query scope
set to the current Azure OpenAI resource. This means that log queries will only include data from
that resource. If you want to run a query that includes data from other resources or data from other
Azure services, select Logs from the Azure Monitor menu. See Log query scope and time range in
Azure Monitor Log Analytics for details.
https://learn.microsoft.com/en-us/azure/azure-monitor/essentials/resource-logs-schema
https://learn.microsoft.com/en-us/azure/azure-monitor/essentials/activity-log
https://learn.microsoft.com/en-us/azure/role-based-access-control/resource-provider-operations#microsoftcognitiveservices
https://learn.microsoft.com/en-us/azure/azure-monitor/logs/scope
18/05/2023, 11:16 Monitoring Azure OpenAI Service - Azure Cognitive Services | Microsoft Learn
https://learn.microsoft.com/en-us/azure/cognitive-services/openai/how-to/monitoring 4/5
Kusto
Here we return a sample of 100 entries and are displaying a subset of the available columns of data in the
logs. The results are as follows:
If you wish to see all available columns of data, you can remove the scoping that is provided by the |
project line:
Kusto
You can also select the arrow next to the table name to view all available columns and associated data
types.
To examine AzureMetrics run:
Kusto
AzureDiagnostics
| take 100
| project TimeGenerated, _ResourceId, Category,OperationName, DurationMs, ResultSignature,
properties_s

AzureDiagnostics
| take 100
AzureMetrics
| take 100
| project TimeGenerated, MetricName, Total, Count, TimeGrain, UnitName
https://learn.microsoft.com/en-us/azure/cognitive-services/openai/media/monitoring/kusto-results.png#lightbox
18/05/2023, 11:16 Monitoring Azure OpenAI Service - Azure Cognitive Services | Microsoft Learn
https://learn.microsoft.com/en-us/azure/cognitive-services/openai/how-to/monitoring 5/5
Azure Monitor alerts proactively notifyyou when important conditions are found in your monitoring data.
They allow you to identify and address issues in your system before your customers notice them. You can
set alerts on metrics, logs, and the activity log. Different types of alerts have different benefits and
drawbacks.
Every organization's alerting needs are going to vary, and will also evolve over time. Generally all alerts
should be actionable, with a specific intended response if the alert occurs. If there's no action for
someone to take, then it might be something you want to capture in a report, but not in an alert. Some
use cases may require alerting anytime certain error conditions exist. But in many environments, it might
only be in cases where errors exceed a certain threshold for a period of time where sending an alert is
warranted.
Errors below certain thresholds can often be evaluated through regular analysis of data in Azure Monitor
Logs. As you analyze your log data over time, you may also find that a certain condition not occurring for
a long enough period of time might be valuable to track with alerts. Sometimes the absence of an event
in a log is just as important a signal as an error.
Depending on what type of application you're developing in conjunction with your use of Azure OpenAI,
Azure Monitor Application Insights may offer additional monitoring benefits at the application layer.
See Monitoring Azure resources with Azure Monitor for details on monitoring Azure resources.
Read Understand log searches in Azure Monitor logs.

